1600mm Dia Cummins 76r/Min Horizontal Directional Drilling Rig

Basic Information
Place of Origin: China
Brand Name: SINOVO
Certification: CE/GOST/ISO9001
Model Number: SHD300
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: International Export Carton Case Package
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 30 set per month
Detail Information
Name: Horizontal Directional Drilling Rig Model: SHD300
Engine: CUMMINS Rated Power: 298*2KW
Max.pullback: 3000KN Max. Thrusting: 3000KN
Spindle Speed: 0-76r/min Backreaming Diameter: 1600mm
High Light:

1600mm Horizontal Directional Drilling Rig


cummins horizontal directional drilling rig


76r/min horizontal directional drilling rig

Product Description

1600mm Dia Trenchless Piping Construction Horizontal Directional Drilling Rig


SHD series Horizontal Directional Drills are mainly used in the trenchless piping construction and re-placement of the underground pipe.The SHD Series Horizontal Directional Drills have the advantages of advanced performance,high efficiency and comfortable operation,Many key components adopt international famous products to guarantee the quality. They are the ideal machines for the construction of the water piping, gas piping,electricity,telecommunication, heating system, crude oil industry.






1. Hydraulic pilot control, provide comfortable operating performance and flexible regulation.
2. Rack and pinion sliding, to ensure the stability of the carriage and the reliability of drive operational. Carriage floating, floating vice technology can greatly protect the drill pipe thread, the service life of the drill pipe 30% increase.
3. Double speed carriage, drilling, dragged back when running at low speed, ensure the smooth construction.The discharge pipe light back and forth, carriage can accelerate sliding, reduce the auxiliary time, improve work efficiency.
4. Host equipped with semi-automatic pipe loading and unloading device,Hengyangmud pump,mud cleaning device,high efficiency and energy saving construction.
5. Support the diverse needs of customers, the machine can option configuration with the automatic (semi-automatic) full-automatic pipe loader, automatic anchoring system, cab, air conditioning wind, cold start, freezing mud, mud washing,mud throttling and other devices.



Technical Parameter:


Model Unit SHD300
Engine   CUMMINS
Rated power KW 298*2
Max.pullback KN 3000
Max. thrusting KN 3000
Spindle torque(max) N.m 110000
Spindle speed r/min 0-76
Backreaming diameter mm 1600



We are a professional horizontal directional drill manufacturer in China.Our horizontal directional drilling rigs are primarily used in trenchless piping construction and replacement of the underground pipes. Having the advantages of advanced performance,high efficiency and ease of operation.Our horizontal directional drills are increasingly used in the construction of the water piping, gas piping, electricity,telecommunication,heating systems,and crude oil industry



Q1.What is the main function of our mining drilling machine?
Ans.: It has different models used for all kinds of working site.

Q2. What is your terms of payment?
Ans.: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and
packages before you pay the balance.

Q3. What is your terms of delivery?

Q4. How about your delivery time?
Ans.: Generally, it will take 7 -10 working days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.

Q5. What is the warranty of our machine?
Ans.:Our main machine enjoys a 1 year warranty(except for the hammer), during this time all accessories broken can be changed for a new one.And we provide videos for machine install and operation.
