Low Noise 100mm Stroke Sludge Drilling Rig Pump Mud Pump For Water injection or mud

Basic Information
Place of Origin: China
Brand Name: SINOVO
Certification: CE/ISO/SGS
Model Number: BW500
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden Case
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 30 sets per month
Detail Information
Model: BW500 Stroke: 100mm
Cylinder Diameter: 95mm Other Name: Sludge Pump,slush Pump
Used For: Drilling Rig Advantages: Stable Operation, Low Noise, Simple Structure, Convenient Disassembly And Maintenance
High Light:

100mm Stroke Drilling Rig Pump


Sludge Drilling Rig Pump

Product Description

Mud Pumps For Drilling Rig With Stable Operation, Low Moise, Simple Structure And Convenient Disassembly And Maintenance


Basic information:


Mud pump is a kind of machine that transports mud or water and other flushing fluid to the borehole during drilling. Mud pump is an important part of drilling equipment.

In the conventional positive circulation drilling, the surface flushing medium, water, mud or polymer flushing fluid, under certain pressure, is sent directly to the bottom of the bit through the high-pressure hose, faucet and the central hole of the drill string, so as to cool the drill bit, remove the cuttings and transport them to the surface.

The commonly used mud pump is piston type or plunger type. The power machine drives the crankshaft of the pump to rotate, and the crankshaft drives the piston or plunger to do reciprocating movement in the pump cylinder through the crosshead. Under the alternate action of the suction and discharge valves, the purpose of pressure delivery and circulation of flushing fluid is realized.



Product features:

1. It can transport suspension slurry with high concentration and viscosity < 10000 PAS and particles.
2. The conveying liquid flow is stable without over flow, pulsation, stirring and shearing of slurry.
3. The discharge pressure has nothing to do with the rotational speed, and a high discharge pressure can be maintained at a low flow rate.
4. The flow is directly proportional to the speed, and the flow can be adjusted by the speed changing mechanism or speed regulating motor.
5. It has strong self-priming ability and can directly suck liquid without installing bottom valve.
6. It can be used to reverse the flow direction of the pump.
7. Stable operation, low vibration and noise.
8. It has simple structure and convenient disassembly and maintenance.


Low Noise 100mm Stroke Sludge Drilling Rig Pump Mud Pump For Water injection or mud 0


Technical Parameters:


Model type BW500
Stroke 100mm
Cylinder diameter 95mm
Pressure 1.8-7MPa
Input torque 335Nm
Input rotating speed 511r/min
