70m Depth 1200mm Width Hydraulic Diaphragm Wall Grab Equipment

Basic Information
Place of Origin: China
Brand Name: SINOVO
Model Number: TG40
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: International Export Carton Case Package
Delivery Time: 7-10 work days
Payment Terms: L/C, D/A
Supply Ability: 30 set per month
Detail Information
Certification: CE/GOST/ISO9001 Name: Diaphragm Wall Grab
Model: TG40 Power Type: Diesel
Depth Of Trench: 70m Width Of Trench: 600-1200mm
Max. Pull Force: 400Kn Track Shoe Width: 3000-4300mm
High Light:

70m hydraulic diaphragm wall grab

,

1200mm hydraulic diaphragm wall grab

,

Hydraulic Diaphragm Wall Grab Equipment


Product Description

70m Depth 1200mm Width Hydralic Diaphragm Wall Grab Equipment



Diaphragm walls are underground structural elements principally used for retention systems and permanent foundation walls. Our TG series hydraulic diaphragm wall grabs are ideal forpit strutting, dam anti-seepage, excavation support, dock cofferdam and foundation element, and are also suitable for the construction of square piles. It is one of the most efficient and versatile construction machines on the market.

The working device is pure mechanical structure, with simple structure, easy to operate, and easy to maintain. Equipped with our professional designed grab bucket, single bucket capacity up to 1.3 cubic meters, greatly improve working efficiency.This equipment’s groove width is 600-1200mm, the maximum groove depth can extent to 70 meters, is the ideal choice of conventional underground construction slot devices.





Technical parameters



  Euro Standards U.S Standards
Width of trench 600-1200mm 24-47in
Depth of trench 70m 230ft
Max. pull force 400kN 89924 lbf
Volume of grab bucker 0.8-1.7 m³ 0.8-1.7 m³
Undercarriage Model CAT336D CAT336D
Engine power 261kW 350hp
Pull force of main winch (The first layer) 200kN 44962lbf
Extendable undercarriage (mm) 800mm 32 in
Track shoe width 3000-4300mm 118-170in
System Pressure 35Mpa 5076psi





Performance



1. Engine power is 261kw, meeting Euro III emission sandard, high power and high durability. Provide stable and reliable power for diaphragm wall grab.
2. Energy saving and consumption reduction: variable weight frame configuration, weight range 18-25T.
3. The upper chassis has a reinforced structure design, and the thickness of the bottom plate is 60mm,which is special for heavy type frame.
4. Center installed winch design, with a compact and reasonable structure, easy maintainence.




Packaging & Delivery
Packaging Details
Nude Packing or by Container.
Port
Tianjin/Shanghai
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 30 To be negotiated
